ZENGTAI 1121 SPDT ON/ON 2 Position Toggle Switch 250V 15A 3-Pin HQ

Product details of ZENGTAI 1121 SPDT ON/ON 2 Position Toggle Switch 250V 15A 3-Pin HQ
ZENGTAI 1121 SPDT ON/ON 2 Position Toggle Switch 250V 15A 3-Pin HQ is a rocket type switch for panels mounting.

Specification of ZENGTAI 1321 SPDT ON/ON 2 Position Toggle Switch 250V 15A 3-Pin HQ
Model : E-TEN1121
Type: SPDT (Latching);
Position : 2 Positions (ON/ON)
Max Power Rating for Resistive load: 15A 250V / 16A 125V
Max Power Rating for DC Resistive load:DC 0.5A 250V / DC 0.9A 125V
Max Power Rating for Lamp: 125V 300W / 250V 600W
Max Power Rating for DC Lamp: DC 30V 3.5A
Max Power Rating for Motor(Single Phase): 250V 400W / 125V 300W
Mounting Thread Diameter : 11 mm / 0.43";Main Body Size : 3 x 2 x 2.1 cm / 1.2" x 0.8" x 0.8" (L*W*H)
Overall Height : 5.8cm / 2.3";Net Weight : 70g
