D1650 2SD1650 600V 3.5A NPN Power Bipolar Junction Transistor TO-3PML

Product details of D1650 2SD1650 600V 3.5A NPN Power Bipolar Junction Transistor TO-3PML
D1650 is 600V, 3.5A, NPN Transistor. This transistor is a type of bipolar junction transistor (BJT) that consists of two n-type semiconductor materials separated by a single p-type material.

Specification D1650 2SD1650 600V 3.5A NPN Power Bipolar Junction Transistor TO-3PML
Type Designator: D1650
Material of Transistor: Si
Polarity: NPN
Maximum Collector Power Dissipation (Pc): 50 W
Maximum Collector-Base Voltage |Vcb|: 1500V
Maximum Collector-Emitter Voltage |Vce|: 600V
Maximum Emitter-Base Voltage |Veb|: 6V
Maximum Collector Current |Ic max|: 3.5A
Max. Operating Junction Temperature (Tj): 150 °C
Transition Frequency (ft): 3 MHz
Forward Current Transfer Ratio (hFE), MIN: 8
Package: TO-3PML
