LM2587 DC-DC Booster Converter Step Up Voltage Regulator 3.5-12V ~ 19-36V

LM2587 DC-DC Booster Converter Step Up Voltage Regulator 3.5-30V ~ 4.0-30V

Specifications:

Input voltage range: 3.5V-30V (output set voltage higher than the input voltage must be guaranteed)

Output voltage range: 4.0V-30V

Input maximum current: 5A (based on power conservation under nominal conditions the output current

Uin * Iin * efficiency = Uout * Iout)

Continuous operating current: 3A (good ventilation conditions, the output voltage and input voltage ratio can not be greater than 3)

Around 90% of the full load efficiency

Application examples:

The 7.4V boost 12V applications in Aeromodelling camera.

Efficient booster circuit adjustable DC-DC boost the input voltage (4 to 30) V adjustable output (5 to 30) the V input Maximum input current 5A efficiency up to 92%, using the dedicated package boost chip beyond the LM2577, not bean large boost IC performance and output drive power up to 30W.
