GY-6500 MPU9250 6-AXIS 6DOF Accelerometer, Gyroscope, Digital Motion Processor Sensor Module

Product details of GY-6500 MPU9250 6-AXIS 6DOF Accelerometer, Gyroscope, Digital Motion Processor Sensor Module
The MPU-6500 is a 6-axis Motion Tracking device that combines a 3-axis gyroscope, 3-axis accelerometer, and a Digital Motion Processor™ (DMP) all in a small 3x3x0.9mm package. It also features a 4096-byte FIFO that can lower the traffic on the serial bus interface, and reduce power consumption by allowing the system processor to burst read sensor data and then go into a low-power mode. With its dedicated I2C sensor bus, the MPU-6500 directly accepts inputs from external I2C devices. MPU-6500, with its 6-axis integration, on-chip DMP, and run-time calibration firmware, enables manufacturers to eliminate the costly and complex selection, qualification, and system level integration of discrete devices, guaranteeing optimal motion performance for consumers. MPU-6500 is also designed to interface with multiple non-inertial digital sensors, such as pressure sensors, on its auxiliary I2C port.

Specification of GY-6500 MPU9250 6-AXIS 6DOF Accelerometer, Gyroscope, Digital Motion Processor Sensor Module
MPU-6500 module (three-axis gyroscope + three-axis acceleration)
Module Model: GY-6500
Use the chip: MPU-6500
Power supply: 3-5v (internal low voltage regulator)
Communication: Standard IIC / SPI communication protocol
Chip built-in 16bit AD converter, 16-bit data output
Gyro range: ±250 500 1000 2000 °/ s
Acceleration range: ±2 ±4 ±8 ±16g
The use of immersion gold PCB, machine welding process to ensure quality
Pin pitch: 2.54mm
Module size: 15mm * 25mm
