MAX9814 Arduino Compatible Microphone Amplifier

Product details of MAX9814 Arduino Compatible Microphone Amplifier
Microphone Amplifier ModuleIt allows you to listen at a normal level by amplifying the sound signals detected by the microphone in projects where sound levels are insufficient and distant sounds are desired to be detected. The maximum gain that can be achieved with this module is 60 decibels. By changing the Gain Pin, the raising rate can be adjusted to 40 or 50 decibels.

Specification of Max9814 Arduino Compatible Microphone Amplifier
Supply Voltage: 2.7v-5.5v @ 3mA current
Output: 2Vpp over 1.25V bias
Frequency Response: 20Hz - 20KHz
Programmable Attack and Swing Rate
Auto gain, maximum select able from 40dB, 50dB or 60dB
Low Input Reference Noise Intensity 30nV /
Low THD: 0.04% (normal)
Low Power Shutdown Mode
Built-in 2V low noise microphone bias
Wide temperature range of -40 ° C ~ + 85 ° C
