433MHz ASK Transmitter STX882 and ASK Receiver SRX882 100 Meters

Product details of 433MHz ASK Transmitter STX882 and ASK Receiver SRX882 100 Meters
Frequency Range: 433 MHZ ASK /OOK modulation mode Super anti-power interference Low-power sleep less than 1uA Low self-radiation Small size Frequency stability and reliability Various international testing standards.

Specification of 433MHz ASK Transmitter STX882 and ASK Receiver SRX882 100 Meters
Features :
Frequency Range: 433 MHz
ASK /OOK modulation mode
Super anti-power interference
Low-power sleep less than 1μA
Low self-radiation
Frequency stability and reliability
Various international testing standards
Antenna dimensions: 36 x 5.5 mm(HxD)

Specification:
SRX882 Receiver:
Supply Voltage: 2.4 – 5.5V
Operating Temperature Range: -30°c ~ 85°c
Latency: 20ms @315MHz, 9ms @433MHz
Consumption: 2.5mA @315MHz, 2.8mA @433MHz
Frequency Range: 315MHz-433.92MHz
Sensitivity: -110 dBm @1.2Kbps
Air Rate: 0.1-9.6 Kbps
Receiver bandwidth: 200 KHz
Dimension (mm): 35 x 10.5 x 6
Weight (gm): 2
Package Includes:
1 x  STX882 Transmitter Module
1 x SRX882 Receiver Module
2 x Antennas
