Solar MC4 Male Female Connector Set

MC4 Male Female M/F Wire PV Cable Connector Set For Solar Panel DIY New
Snap-in locking
Locking by safety lock clip PV-SSH4 in accordance with NEC 2011, can be released only with tool
Proven MULTILAM technology with high long-term stability, which ensures consistently low performance loss throughout the entire service life of the plug connector
Tried and tested plug connectors, 12 years of experience in the field
Available for assembly with cross-sections of 10mm²
Also available as ready made leads
Leads made to customer's specifications

Type: Solar connector
Rated current: 30A(2.5-6mm2)
Rated voltage: 1000v DC
Test voltage: 6000V(50Hz, 1min)
Overvoltage type/pollution degree: CAT Ⅲ /2
Contact resistance of plug connector: 1mΩ
Contact material: Copper, Tin-plated
Insulation material: PPO
Degree of protection: IP2X/IP67
Flame class: UL94-VO
Safety class: II
Suitable cable: OD 4.5-8.5(2.5-6.0mm2)
Insertion force/withdrawal force: ≤50N/≥50N
Connecting system: Crimp connection
Temperature range:-40C~+125C
