2.4Ghz Foldable 2dbi WiFi Antenna Male SMA Connector

Product details of 2.4Ghz Foldable 2dbi WiFi Antenna Male SMA Connector
This is a tiny 2.4 Ghz Foldable 2dbi WiFi antenna, which provides broad coverage. It is a coaxial sleeve design with an omni-directional pattern. It is ideally suited for IEEE 802.11b and 802.11g wireless LANs.

Specification of 2.4Ghz Foldable 2dbi WiFi Antenna Male SMA Connector
Color: Black
Material: Copper
Standard: 2.4GHz
Frequency range: 2400~2500MHz
Interface: SMA
Gain: 2dBi
Coverage range: 80m
Antenna length: 26cm
V.S.W.R.: < 1.5
Polarization: Vertical
Non-Circularity (dB): +/- 0.5
Impedance (ohm): 50
Lightning protection: Direct ground
Maximum input power (W): 50W

Mechanical specifications:
Radome Material: EVA
Radome Color: Gray
Dimension (mm): 110(Unbend) 92(Bend)
Tailing Cable Length (mm): 120mm
Packing Size (mm): 295mm × 110mm × 60mm
Wight (Kg): 0.009 / 12kg
Application condition: Indoor
Operating Temperature: -40’C~+70’C
Reposition Temperature: -55’C~+80’C
Dimensions: 10.24 in x 0.39 in x 0.39 in (26.0 cm x 1.0 cm x 1.0 cm)
Weight: 0.46 oz (13 g)
