Product details of GY-521 MPU-6050 3-Axis Digital Peb-axis Gyroscope Acceleration Module
A 3-axis gyroscope and a 3-axis accelerometer are combined together on the same silicon die with an onboard Digital Motion Processor. Easy to get it fit into your project! It is very accurate, as GY-521 Mpu6050 Module contains 16-bits analog to digital conversion hardware for each channel. Therefor Three axis Gyrometer captures the x, y, and z channel at the same time. The sensor uses the I2C-bus to interface with the Arduino.

Specification of GY-521 MPU-6050 3-Axis Digital Peb-axis Gyroscope Acceleration Module
Build in ultra low noise linear LDO voltage regulator
Build-in on board filters, which reduce noise from motor and other high current electronics
All sensors connected to I2C bus
You can easily select two I2C address for MPU6050 by soldered jumper
Tri-Axis angular rate sensor (gyro) with a sensitivity up to 131 LSBs/dps and a full-scale range of ±250, ±500, ±1000, and ±2000dps
Tri-Axis accelerometer with a programmable full scale range of ±2g, ±4g, ±8g and ±16g
Digital Motion Processing™ (DMP™) engine offloads complex MotionFusion, sensor timing synchronization and gesture detection
Embedded algorithms for run-time bias and compass calibration. No user intervention required
Power LED
Input Voltage: 2.3 – 3.4V
Build in Logic level converter for I2C
Digital-output temperature sensor
Dimensions 20x16mm
Designed for 5V logic level
